Output Power
|
70W + 70W ( 1kHz, T.H.D. 0.5 %, 8Ω, 20kHz LPF ), 140W + 140W ( 1kHz, T.H.D. 0.5 %, 4Ω, 20kHz LPF )
|
|
FTC Output Power
|
70W + 70W ( 1kHz, T.H.D. 0.5 %, 8Ω, 20kHz LPF ), 140W + 140W ( 1kHz, T.H.D. 0.5 %, 4Ω, 20kHz LPF )
|
|
Load Impedance
|
4Ω-16Ω
|
|
Frequency Response - PHONO (MM)
|
2.5 mV / 47 kΩ
|
|
Frequency Response - PHONO (MC)
|
300 uV /100 Ω
|
|
Frequency Response - LINE
|
200 mV / 22 kΩ
|
|
Analogue Input Terminal
|
LINE x 2 (LINE1, LINE2 / MAIN IN), PHONO (MM/MC) x1
|
|
Digital Input Terminal
|
Optical digital x2 (OPT 1, OPT 2), Coaxial digital x2 (COAX 1, COAX 2), USB-B x1 (PC)
|
|
Analogue Output Terminal
|
LINE OUT x1, PRE OUT x1
|
|
Headphone Output
|
Yes, Stereo Φ6.3 mm
|
|
PC (USB-B)
|
USB 2.0 high-speed, USB Audio Class 2.0, Asynchronous mode
|
|
Support Codec
|
PCM Yes (32, 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384 kHz / 16, 24, 32 bit), DSD Yes (2.8 MHz, 5.6 MHz, 11.2 MHz)
|
|
DSD control mode
|
ASIO Native mode, DoP mode
|
|
Power Supply
|
AC 120 V ,60 Hz
|
|
Power Consumption
|
95W
|
|
Dimensions (W x H x D)
|
16-15/16 x 5-13/16 x 16-27/32 inch
|
|
Weight
|
Approx. 28 lbs
|
|
Accessories
|
AC Cord, Remote Control, Batteries for Remote Control, Owner's Manual
|
